Good Compact Heat Pipe Vacuum Tube Pressurized Solar Water Heater
Compact High pressure solar water heaterMain Features :High pressure : Working pressure 6 bar, Maximum 9 barHigh efficient : 3 Target high efficient vacuum tubes, heatpipe condensor maximum 330CIndirect connect: No water flow in vacuum tubes5 years warranty, 20 years lifeAnt-corrosion : inner tank, ......
Send Inquiry
Product Description
Compact High pressure solar water heater
Main Features :
High pressure : Working pressure 6 bar, Maximum 9 bar
High efficient : 3 Target high efficient vacuum tubes, heatpipe condensor maximum 330C
Indirect connect: No water flow in vacuum tubes
5 years warranty, 20 years life
Ant-corrosion : inner tank, inlet outlet SUS304 2B
Anti-freeze : -40.C
Compact high pressure heatpipe solar water heater
working pressure 6 bar, maximum pressure 9 bar
Antifreeze heatpipe solar water heater
solar thermal water heater
Solar Energy water Heater
Compact pressurized heatpipe solar water heater
Heatpipe solar water heater
maximum pressure 9 bar-tube diameter 70mm
Compact pressurized, heatpipe, closedloop,anti-freezing -40.C
Solar water heater-Heatpipe compact high pressure
high pressure solar water heater
Heatpipe solar water heater, normal working pressure 6 bar
Maximum pressure: 9 bar
Inner tank: 1.2 SUS304 2B food grade stainless steel,anti-corrosion
Outer tank: 0.4mm SUS304 2B or BA food grade stainless steel or 0.5mm galvanized steel
Frame: 1.2mm stainless steel or 1.5mm galvanized steel or anodized aluminum (for coast area with corrosion problem )
Tubes: High birosiligate glass tube with AL-N-AL coating or AL-N-AL-CU-SS Three target coating
Electric alternative heating: 220V or 110V 1500W to 3000W
Heating efficiency: 4 hours heat to 90C degree
Solar Water Heater
MODEL Tank capacity
(L) Tube quantity Absorber area
(m2) Loading quantity
20GP/40HQ(set)
FT-SS-HP-420-45/1500-15 84 15 0.80 63/146
FT-SS-HP-420--47/1500-18-C 100 18 0.96 56/130
FT-SS-HP-420-47/1500-20-C 111 20 1.06 48/111
FT-SS-HP-420-47/1500-22-C 121 22 1.17 15/100
FT-SS-HP-420-47/1500-24-C 133 24 1.28 41/88
FT-SS-LP-420-47/1500-25-C 138 25 1.33 38/84
FT-SS-HP-420-47/1500-28-C 154 28 1.49 35/75
MODEL Tank capacity
(L) Tube quantity Absorber area
(m2) Loading quantity
20GP/40HQ(set)
FT-SS-HP-470-45/1500-15 113 15 0.80 63/146
FT-SS-HP-470--47/1500-18 139 18 0.96 56/130
FT-SS-HP-470-47/1500-20 155 20 1.06 48/111
FT-SS-HP-470-47/1500-22 170 22 1.17 45/100
FT-SS-HP-470-47/1500-24 186 24 1.28 41/95
FT-SS-HP-470-47/1500-25 194 25 1.33 40/93
FT-SS-HP-470-47/1500-28 218 28 1.49 38/88
FT-SS-HP-470-45/1500-30 234 30 1.60 34/79.
Main Features :
High pressure : Working pressure 6 bar, Maximum 9 bar
High efficient : 3 Target high efficient vacuum tubes, heatpipe condensor maximum 330C
Indirect connect: No water flow in vacuum tubes
5 years warranty, 20 years life
Ant-corrosion : inner tank, inlet outlet SUS304 2B
Anti-freeze : -40.C
Compact high pressure heatpipe solar water heater
working pressure 6 bar, maximum pressure 9 bar
Antifreeze heatpipe solar water heater
solar thermal water heater
Solar Energy water Heater
Compact pressurized heatpipe solar water heater
Heatpipe solar water heater
maximum pressure 9 bar-tube diameter 70mm
Compact pressurized, heatpipe, closedloop,anti-freezing -40.C
Solar water heater-Heatpipe compact high pressure
high pressure solar water heater
Heatpipe solar water heater, normal working pressure 6 bar
Maximum pressure: 9 bar
Inner tank: 1.2 SUS304 2B food grade stainless steel,anti-corrosion
Outer tank: 0.4mm SUS304 2B or BA food grade stainless steel or 0.5mm galvanized steel
Frame: 1.2mm stainless steel or 1.5mm galvanized steel or anodized aluminum (for coast area with corrosion problem )
Tubes: High birosiligate glass tube with AL-N-AL coating or AL-N-AL-CU-SS Three target coating
Electric alternative heating: 220V or 110V 1500W to 3000W
Heating efficiency: 4 hours heat to 90C degree
Solar Water Heater
MODEL Tank capacity
(L) Tube quantity Absorber area
(m2) Loading quantity
20GP/40HQ(set)
FT-SS-HP-420-45/1500-15 84 15 0.80 63/146
FT-SS-HP-420--47/1500-18-C 100 18 0.96 56/130
FT-SS-HP-420-47/1500-20-C 111 20 1.06 48/111
FT-SS-HP-420-47/1500-22-C 121 22 1.17 15/100
FT-SS-HP-420-47/1500-24-C 133 24 1.28 41/88
FT-SS-LP-420-47/1500-25-C 138 25 1.33 38/84
FT-SS-HP-420-47/1500-28-C 154 28 1.49 35/75
MODEL Tank capacity
(L) Tube quantity Absorber area
(m2) Loading quantity
20GP/40HQ(set)
FT-SS-HP-470-45/1500-15 113 15 0.80 63/146
FT-SS-HP-470--47/1500-18 139 18 0.96 56/130
FT-SS-HP-470-47/1500-20 155 20 1.06 48/111
FT-SS-HP-470-47/1500-22 170 22 1.17 45/100
FT-SS-HP-470-47/1500-24 186 24 1.28 41/95
FT-SS-HP-470-47/1500-25 194 25 1.33 40/93
FT-SS-HP-470-47/1500-28 218 28 1.49 38/88
FT-SS-HP-470-45/1500-30 234 30 1.60 34/79.
| MODEL | Tank capacity | Tube quantity | Absorber area (m 2 ) | Loading quantity 20GP/40HQ (set) |
| FT-SS-HP-470-58/1800-10-C | 85 | 10 | 0.82 | 60/140 |
| FT-SS-CP-470-58/1800-12-C | 100 | 12 | 0.98 | 55/130 |
| FT-SS-CP-470-58/1800-18-C | 150 | 18 | 1.46 | 41/95 |
| FT-SS-CP-470-58/1800-20-C | 167 | 20 | 1.62 | 37/86 |
| FT-SS-CP-470-58/1800-24-C | 200 | 24 | 1.96 | 32/74 |
| FT-SS-CP-470-58/1800-30-C | 250 | 30 | 2.47 | 25/58 |
| Model Explanation : | ||||
